| Standards |
 Wireless: IEEE 802.11b, 802.11g
USB 2.0 Standard |
| Data Rate |
802.11g : Up to 54Mbps (6/9/12/18/24/36/48/54)
802.11b: Up to 11Mbps (1/2/5.5/11) |
| Dimension |
86.5 x 26 x 12 mm |
| Interface |
USB 2.0 Standard |
| Antenna Type |
Embedded Antenna (2dBi Max) |
| Emission Type |
DSSS and OFDM |
| RF Frequency |
2412 ~ 2462 MHz (North America)
2412 ~ 2472 MHz (General Europe)
2412 ~ 2484 MHz (Japan) |
| Opt. Channel |
1 ~ 11 Channels (North America)
1 ~ 13 Channels (General Europe)
1 ~ 14 Channels (Japan) |
| Output power |
15 dBm (typical) |
| Power Consumption |
802.11g: TX 500mA, RX 400mA, Standby 30mA
802.11b: TX 500mA, RX 400mA, Standby 30mA |
| LED |
Power: Slow rate blink
WLAN: Blink for activity |
| Frequency Stability |
Within ± 20 ppm |
| Data Modulation Type |
64QAM, 16QAM, BPSK, QPSK, CCK |
| Power |
3.3Volt ± 5% |
| Network |
Auto-switch to use 802.11g or 802.11b mode
Supports Ad-Hoc, Infrastructure WLAN network
Wireless roaming
Data rate auto fall-back under noisy environment or longer range distance
Site survey with profile function |
| Security |
WEP 64/128 bit
WPA-PSK |
| Configuration & Management |
Management Utility supports 2000 and XP |
| Operating Temperature |
0°C ~ +40°C. |
| Operating Humidity |
5% - 95% non-condensing. |
| Non-Operating Temperature Conditions (including warehouse) |
-10°C ~ 65°C. |
| Non-Operating Humidity conditions (including warehouse) |
from 5% ~ 95% non-condensing. |
